Nvidia's next-generation AI chip platform, codenamed Feynman, represents a major architectural leap that ties together TSMC's most advanced process node, new panel-level packaging, and native optical interconnects. Here is everything known so far about the platform, its supporting manufacturing ecosystem, and what it means for the broader AI supply chain.
Feynman Architecture and Performance Targets
Nvidia is targeting mass production of Feynman in the second half of 2028, with the company reportedly accelerating its supply chain to meet that timeline . At GTC 2026, Nvidia provided the first deep technical dive into the architecture .
The chip is built on TSMC's A16 process (a 1.6nm-class node), which features gate-all-around (GAA) transistors and backside power delivery. TSMC plans A16 mass production starting in the second half of 2026, with Nvidia expected to be the lead customer .
Studio Global AI
Continue your research
This page includes a source-backed answer you can continue inside Studio Global.
What is the short answer to "Nvidia Feynman AI Chip: TSMC A16 Process, CoPoS Packaging, and 2028 Mass Production Timeline"?
Nvidia's next generation Feynman AI chip platform is targeting mass production in the second half of 2028, using TSMC's A16 (1.6nm class) process with GAA transistors, SoIC 3D stacking, CoPoS panel level packaging for...
Nvidia Feynman AI Chip: TSMC A16 Process, CoPoS Packaging, and 2028 Mass Production Timeline
Nvidia's next generation Feynman AI chip platform is targeting mass production in the second half of 2028, using TSMC's A16 (1.6nm class) process with GAA transistors, SoIC 3D stacking, CoPoS panel level packaging for...
Published byEdited with DeepSeek-V4-FlashImages generated with GPT Image 1.5
Nvidia's next generation Feynman AI chip platform is targeting mass production in the second half of 2028, using TSMC's A16 (1.6nm class) process with GAA transistors, SoIC 3D stacking, CoPoS panel level packaging for...
What are the key details about Nvidia's next-generation Feynman AI chip platform — including its target mass production in the second half oNvidia Feynman architecture concept: TSMC A16 process with SoIC 3D stacking, CoPoS packaging, and native co-packaged optics for AI inference at 10x lower cost-per-token.
AI Prompt
Create a landscape editorial hero image for this Studio Global article: What are the key details about Nvidia's next-generation Feynman AI chip platform — including its target mass production in the second half o. Article summary: Here is a comprehensive breakdown of the key details currently available across these interlocking topics.. Topic tags: general, general web, user generated. Style: premium digital editorial illustration, source-backed research mood, clean composition, high detail, modern web publication hero. Use reference image context only for broad subject, composition, and topical grounding; do not copy the exact image. Avoid: logos, brand marks, copyrighted characters, real person likenesses, fake screenshots, UI text, readable text, watermarks, charts with fake numbers, clickbait thumbnails, icons, and tiny thumbnail layouts. Make it useful as an illustrative visual, not
openai.com
Nvidia's next-generation AI chip platform, codenamed Feynman, represents a major architectural leap that ties together TSMC's most advanced process node, new panel-level packaging, and native optical interconnects. Here is everything known so far about the platform, its supporting manufacturing ecosystem, and what it means for the broader AI supply chain.
Feynman Architecture and Performance Targets
Nvidia is targeting mass production of Feynman in the second half of 2028, with the company reportedly accelerating its supply chain to meet that timeline . At GTC 2026, Nvidia provided the first deep technical dive into the architecture .
The chip is built on TSMC's A16 process (a 1.6nm-class node), which features gate-all-around (GAA) transistors and backside power delivery. TSMC plans A16 mass production starting in the second half of 2026, with Nvidia expected to be the lead customer .
Studio Global AI
Continue your research
This page includes a source-backed answer you can continue inside Studio Global.
What is the short answer to "Nvidia Feynman AI Chip: TSMC A16 Process, CoPoS Packaging, and 2028 Mass Production Timeline"?
Nvidia's next generation Feynman AI chip platform is targeting mass production in the second half of 2028, using TSMC's A16 (1.6nm class) process with GAA transistors, SoIC 3D stacking, CoPoS panel level packaging for...
In terms of performance, Feynman targets 10× lower cost-per-token and 5× faster inference than prior-generation architectures .
Advanced Packaging: SoIC, CoPoS, and CPO
Feynman will combine three advanced packaging technologies simultaneously:
SoIC (System-on-Integrated-Chips) — TSMC's hybrid bonding technology for 3D stacking of chiplets and memory. This is a key enabler for Feynman's high-bandwidth design .
CoPoS (Chip-on-Panel-on-Substrate) — TSMC's next-generation packaging that replaces round wafers with large rectangular panels, targeting ultra-large packages exceeding 9.5× reticle size. Analyst Ming-Chi Kuo states CoPoS is slated for mass production in 2H 2028, and Feynman is expected to be the first customer .
Co-packaged optics (CPO) — Feynman GPUs are designed to integrate silicon photonics directly onto the GPU package, transitioning scale-up from copper backplanes to native optical interconnect .
TSMC's Capacity Ramp: SoIC, CoWoS, and New Plants
To support Feynman and other high-volume customers, TSMC is aggressively expanding its advanced packaging capacity:
SoIC capacity: Industry projections estimate SoIC output could reach approximately 65,000 wafers per month (wfpm) by 2028 to align with mass adoption in AI accelerators . Other estimates project SoIC reaching 14,000 wfpm by end-2026 and 28,000 wfpm by end-2027 .
CoWoS capacity: TSMC is raising its CoWoS targets to between 115,000 and 140,000 wfpm by end-2026, and approximately 170,000 to 190,000 wfpm by 2027. JPMorgan channel checks project CoWoS reaching 220,000–225,000 wfpm by end-2028 . TSMC's CoWoS capacity has been growing at an 80% CAGR between 2022 and 2027 .
New facilities: TSMC's advanced packaging plants AP7 in Chiayi and AP8 in Tainan are reportedly ahead of schedule, with construction accelerating . Two factories from one of these parks' first phases have already entered mass production as of June 2026 . AP7 is described as TSMC's biggest advanced packaging campus, with multiple phases planned to support SoIC and CoPoS . AP8 focuses on CoWoS and is expected to eventually house monthly capacity exceeding 40,000 wafers .
Nvidia Spectrum-X Ethernet Photonics CPO Switches: In Production Now
While Feynman is still two years away, Nvidia's co-packaged optics technology has already entered mass production in the form of Spectrum-X Ethernet Photonics switches:
May 2026: Nvidia announced the Vera Rubin platform, introducing Spectrum-X Ethernet Photonics as "now in production" .
June 2026: Nvidia confirmed full mass production of the switches, built on Spectrum-6 switching silicon with co-packaged optics .
July 2026: TrendForce reported Nvidia had begun volume shipments of Spectrum-X CPO switches to select partners .
August 14, 2026: Nvidia officially declared Spectrum-X Ethernet Photonics had entered full mass production, calling it the "world's first 200G/lane CPO Ethernet switch system in production," built with Hon Hai, Lumentum, SPIL, TFC, and TSMC .
Performance claims for the switches include 4× fewer lasers, 5× lower power consumption, 10× better mean time between failures, and up to 70% power savings versus conventional pluggable optics .
Broader AI Supply Chain Implications
Nvidia's roadmap is increasingly dictating TSMC's capital expenditure cycle across several dimensions:
Process node lockstep: Nvidia is the lead customer for TSMC's most advanced nodes — Blackwell on 4nm, Rubin on 3nm, Feynman on A16 (1.6nm) — meaning every new Nvidia generation pulls TSMC's next node ramp forward .
Packaging as the bottleneck: With Feynman requiring SoIC, CoPoS, and CPO simultaneously, TSMC's capacity planning for advanced packaging is increasingly driven by Nvidia's product cadence rather than general foundry demand .
CPO inflection now: The Spectrum-X CPO ramp in 2026–2027 serves as a real-world production test for TSMC's COUPE silicon photonics platform — exactly the technology Feynman will rely on at scale .
Facility acceleration: TSMC is pulling forward construction at AP7 (Chiayi) and AP8 (Tainan) specifically to meet Nvidia's 2028 Feynman timeline .
Capex cycle tightening: TSMC's multi-year N2/A16 capacity expansion, aiming for ~90,000 WSPM by end-2026 with 70% year-over-year growth, is increasingly synchronized to Nvidia's two-year GPU architecture cadence .
Key uncertainty: Some reports mention Feynman may also use Intel's advanced packaging or glass substrates, which would complicate the exclusive TSMC-Nvidia relationship. This remains unconfirmed by primary sources .
In terms of performance, Feynman targets 10× lower cost-per-token and 5× faster inference than prior-generation architectures .
